Datavideo VP-605H All-in-One Cable Repeater

Description

The Datavideo VP-605H All-in-One Cable Repeater is a repeater for the CB-22H or CB-23H cable. This repeater allows two 164′ all-in-one cables to be joined together for a cable run of 328′. You can also link multiple VP-605H units and all-in-one cables together to create a cable run of 1968′ or more.

All-in-one signal repeater of SDI, composite video, power, and intercom cables up to 328′.



In The Box:

1 x VP-605H unit



Specifications:

Video and Signal
Input: HD/SD-SDI, CV, Talkback, Tally, DC in
Output: HD/SD-SDI, CV, Talkback, Tally, DC out

Standard
SD: SMPTE 259M
HD: SMPTE 292M

Video Format
SD: 480i, 576i
HD: 720p 50/59.94/60
1080i 50/59.94/60
1080p 24/25/30

Audio
SDI Embedded Audio

Power
DC 25V~48V

Dimension (LxWxH)
226 x 210 x 61 mm

Weight
1.1 kg

Operating Temp. Range
0~40 °C
